1.1 Overview
The APM-10 series is a 10” touchscreen monitor that builds to withstand commercial
grade open frame monitor, with stylish thin cable management bracket and versatile
design APM-10 is an exceptional choice for applications for all business sectors and well
suited for point-of-sales, point-of-information, point-of-service and interactive signage.
1.2 Feature
 Cable management bracket design for easy organize cable.
1.3 Specifications
LCD Touch Panel
Size
10” TFT LCD
Brightness
500 cd/m
2
(Non-touch screen)
425 cd/m
2
(P-CAP)
Number of Pixels
1280(H) x 800(V)
Touch Type
P-CAP/ 10 points
Environment
Compliance
IPX0
Operating Temperature
0C ~ 50C
Storage Temperature
-20C ~ 60C
Operating Humidity
20% ~ 80% RH, non-condensing
Mounting
VESA 100 mm x 100 mm
Dimension (W x H x D)
260.67mm x 183.37mm x 39.4 mm
Net Weight
1.4 kg
Gross Weight
2.4 kg
