TES APM-10 - Timing Table Chart; EDID Data

19
2.3.2 Timing Table Chart
Mode
Resolution
H-Freq.
(KHz)
Band Width
(MHz)
Polarity
H
V
1
640x480 60 Hz
31.47
25.175
－
－
2
800x600 60 Hz
37.88
40
＋
＋
3
1024x768 60 Hz
48.363
65
－
－
4
1280x800 60 Hz
49.702
83.5
－
＋
Note: If input H-display >1280 pixel or V-display>800 lines or V-Sync >60Hz, then
OSD shall display warning out of range.
2.3.3 EDID Data
DP/HDMI
The monitor assembly shall provide a display communications channel that
conforms to VESA DDC2B hardware requirements. This configuration shall contain
the 256-byte EDID file as specified by VESA EDID Standard.
VGA
The monitor assembly shall provide a display communications channel that
conforms to VESA DDC2B hardware requirements. This configuration shall contain
the 128-byte EDID file as specified by VESA EDID Standar
