Tescom NEOLINE PLUS 1102ST - Rear Panel View (Tower Type)

24
USER MANUAL
NEOLINE PLUS � 1/1 � 1-3 kVA � ONLINE UPS
24
2-1. Rear panel view (Tower type)
1. AC input
2. Input circuit breaker
3. USB communication port
4. RS-232 communication port
5. SNMP intelligent slot
6. External battery connection (only available for L model)
7. Output receptacles
8. Output circuit breaker
9. Output terminal
24
2-1. Rear panel view (Tower type)
1. AC input
2. Input circuit breaker
3. USB communication port
4. RS-232 communication port
5. SNMP intelligent slot
6. External battery connection (only available for L model)
7. Output receptacles
8. Output circuit breaker
9. Output terminal
