Tescom TEOS Series - Page 54

17
 09: Maximum battery discharging time setting
Interface
Setting
Parameter 3:
000~999: Set the maximum discharging time from 0 min. to 999
min. UPS will shut down to protect battery after discharging time
arrives. The default value is 990 min.
DIS: Disable battery discharge protection and backup time will
depend on battery capacity.
 10: reserved
Interface
Setting
reserved
 11: reserved
Interface
Setting
reserved
 12: reserved
Interface
Setting
reserved
 13: Battery voltage calibration
Interface
Setting
Parameter 2: Select “Add” or “Sub” function to calibrate battery
voltage to real figure.
Parameter 3: The voltage setting range is from 0V to 5.7V. The
default value is 0V.
