5 First steps
9
5 First steps
5.1. Commissioning
Installing the sensor
1. Unscrew the protective cap (1) from the sensor head (counter-
clockwise).
2. Take the sensor (2) out of its protective film packaging.
3. Carefully push the three sensor wires into the sockets in the
sensor head, until they are no longer visible.
NOTICE
Malfunction due to damaged sensor wires!
> Do not damage sensor wires.
4. Put the protective cap on the sensor and tighten by turning in a
clockwise direction.
Insert batteries
1. Using a screwdriver, push down the locking clip on top of the
handle.
2. Slide the top part of the handle down.
3. Insert two mono (D) type batteries. Observe the polarity!
