Maintaining the product24
3 Unlock halfshell elements and remove (
➂
).
4 Remove adaptor and hose (
➃
), Push thermo -
couple out of its holder (
➄
) and disconnect cable
from thermocouple (
➅
).
5
Connect lines to the new thermocouple
(
➆
, white -, green +) and push thermocouple
into holder again.
6
Connect adaptor and hose to thermocouple (
➇
).
Adjust lines and hoses (
➈
) and attach halfshells.
7 Attach sealing cap and turn anticlockwise
(as far as possible, note markings).
8 Attach halfshell handles and close screws.
