Perform draught measurement
A flue gas probe must be connected.
The pressure socket of the instrument must be free (i.e. unpressurized, not closed).
1 ➝ Measurements ➝➝Draught measurement ➝ .
2 Start measurement: .
- Draught zeroing (5s).
3 Position the flue gas probe in the hot spot (area of the highest flue gas temperature).
The display showing the maximum measured flue gas temperature (FT max) helps
when positioning the probe.
- The reading is displayed.
4 End measurement: .
5 Save values to the clipboard: ➝ or .
Perform flue gas measurement
1 ➝ Measurements ➝➝Flue gas ➝ .
- Possibly: Gas zeroing (30 s).
2 Select fuel ➝ .
3 Start measurement: .
4 End measurement: .
5 Save values to the clipboard: ➝ or .
Creating a new location
1 ➝ Folder / Location ➝ .
2 ➝ New location ➝ .
3 Select location ➝ .
4 Enter values ➝ .
5 Perform steps 3 and 4 for further criteria accordingly.
6 .
Enabling location
1 ➝ Folder / Location ➝ .
2 Select location ➝ .
- The location is activated and the menu Measurements is opened.
OK OK
Finished
Next
Edit
Options
SaveClipboardOptions
Clipboard
OK
OK
OK
OK
OK
OK OK
SaveOptions
