TESTO 570 Series User Manual

7 Using the product
19

The measurement view is displayed.
4
Connect the refrigerant hoses.
4.1
Close the valve positioners.
4.2
Connect the refrigerant hoses for low-pressure side (blue) and high-
pressure side (red) to the measuring instrument.
4.3
Connect the refrigerant hoses to the system.
5
Connect testo 115i or fixed cable probes.
6
Set refrigerant.
6.1
Press the key [▼] (Rxx) (refrigerant number according to ISO 817).

The refrigerant menu opens and the
current refrigerant is highlighted.

TESTO 570 Series Specifications

General

Temperature Accuracy	±0.5 °C
Temperature Measurement Range	150°C
Vacuum Measurement	Yes
Data Logging	Yes
Display	LCD
Interfaces	Bluetooth, USB
Storage Temperature	-20 to +60 °C
Operating Temperature	-10 to 50°C
