TESTO 816-1 User Manual

3 Specifications
10
Effect of the windscreen
Frequency weighting
Frequency [Hz] dBA(dB) dBC(dB) Error limits (dB)
20 -50.5 -6.2 ±3.5
31.5 -39.4 -3.0 ±3.5
63 -26.2 -0.8 ±2,5
125 -16.1 -0.2 ±2,0
250 -8.6 0.0 ±1,9
500 -3.2 0.0 ±1,9
1000 0.0 0.0 ±1,4
2000 1.2 -0.2 ±2,6
4000 1.0 -0.8 ±3,6
8000 -1.1 -3.0 ±5,6
Frequency weighting characteristics

TESTO 816-1 Specifications

General

Accuracy	1.4 dB
Resolution	0.1 dB
Control type	Buttons
Product type	Digital
Product color	Black
Time weighting	Fast, Slow
Frequency range	20 - 8000 Hz
Measuring range	30 - 130 dB
Min/max function	Yes
Backlight display	-
Frequency weighting	A-weighting, C-weighting
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Battery type	AA
Power consumption (typical)	0.3 W
Number of batteries supported	4

Weight and Dimensions

Depth	42 mm
Width	83 mm
Height	272 mm
Weight	390 g
