TESTO 816-1 User Manual

5 Using the product
21
Saving a measurement series
When measurement series storage is activated, most functions
(individual value storage, storage interval setting, frequency
weighting, time weighting) are deactivated.
1. Press the key.
- lights up and the readings are stored.
2. Press the key again.
- The storage of readings is completed.
Deleting a measurement series memory
1. Switch the instrument off.
2. Hold down the key and the key.
- While the keys are held down: CLr is displayed, SURE flashes
and a countdown (5 seconds) starts.
3. Once the countdown is complete, release the keys.
- The memory is deleted.
Displaying a measurement series
Stored measurement series are displayed and evaluated via the
PC software, see 7.7 Data Logger, page 28.
5.12. Using AC / DC signal output
Specifications
AC: 1 Vrms at full deflection, output impedance approx. 100 ohms,
output signal via standard 3.5mm jack plug (see illustration below).
DC: Output 10mV / dB, output impedance 1 kohm, output signal via
standard 3.5mm jack plug (see illustration below).
DC Signal
AC Signal
Ground

TESTO 816-1 Specifications

General

Accuracy	1.4 dB
Resolution	0.1 dB
Control type	Buttons
Product type	Digital
Product color	Black
Time weighting	Fast, Slow
Frequency range	20 - 8000 Hz
Measuring range	30 - 130 dB
Min/max function	Yes
Backlight display	-
Frequency weighting	A-weighting, C-weighting
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Battery type	AA
Power consumption (typical)	0.3 W
Number of batteries supported	4

Weight and Dimensions

Depth	42 mm
Width	83 mm
Height	272 mm
Weight	390 g
