53. Product description
3. Product description
This chapter provides an overview of the components of the product and their
functions.
3.1 Display and operating elements
Overview
Infrared sensor
Humidity module
(standard with 0563 8451; retrofittable for 0563 8450)
Measurement trigger
Battery compartment
IR diode for printer
Display
Slide switch
Operating buttons
Probe socket
USB interface
Button functions
Button Functions
Change configuration settings
Printout of values on Testo IR printer
Instrument configuration: activate adjustment
Store a measurement protocol
Measurement and instrument configuration menu: apply values and
jump to next setting menu
Switch between possible display images
Measurement and instrument configuration menu: change setting values
