TESTO 880 - Menu functions

6 Using the product
23
6 Using the product
6.1. Menu functions
6.1.1. Measuring functions
1-point measurement
The 1-point measurement is the standard measuring function.
If this is activated (
), all available options can be selected via
the quick select buttons.
> [OK] | Measurement | [OK] | 1-point measurement | [OK].
If the 1-point measurement is activated, the crosshairs can be
moved using the Joystick on frozen and saved images to read
off the individual temperatures.
With saved images, the 1-point measurement must be
activated via the menu for the respective opened picture.
2-point measurement
The 2-point measurement has 2 crosshairs with which
individual temperatures can be read off. If this function is
activated (
), the quick select buttons are fixed with the
functions Temperature 1 and Temperature 2.
With frozen images, only the activated crosshairs can be
moved.
With saved images, the 2-point measurement must be
activated for the respective opened picture.
1. [OK] | Measurement | [OK].| 2-point measurement | [OK].
2. Select left or right Temperature 1 or Temperature 2 quick
select button to activate one of the two crosshairs.
- The activated crosshairs are shown red.
3. Use the Joystick to move the activated crosshairs in order
to read off the individual temperatures.
Measuring function Cold-/Hotspot
Coldspot/Hotspot shows the min and max temperature value
on the display. If this function is activated (
), the quick select
buttons are fixed with the functions Coldspot and Hotspot.
