6 Using the product
27
2. Move Joystick left/right to select the desired option: Auto-
scaling (
), min. value ( ), temperature range ( ) or max.
value ( )
- The selected option has an orange border (
).
3. With the selection of min. value, temperature range or max.
value: Move Joystick up/down to change the value(s).
- Changes are applied immediately so that the effects on the
display of the infrared image can be checked directly.
4. Close dialogue with [OK] or [Esc].
- The changes are saved.
6.1.4. Display...
Select display options
The presentation can be adapted by means of showing/hiding
the following elements: Crosshairs, temperature scale and quick
select buttons.
Hidden function keys can be shown again by pressing a quick
select button: The first press of the button shows the function
keys again. To trigger a function, the button must be pressed
again.
1. [OK] | Display… | [OK].
- The Display options dialogue is opened.
2. Move Joystick up/down to select the desired option.
- The selected option has an orange border (
).
3. Activate (
) or deactivate ( ) option with [OK].
4. Confirm settings with the [Apply] quick select button.
or
Discard settings with [Esc].
6.1.5. Emissivity...
Emissivity
The emissivity describes the capability of a body to emit
electromagnetic radiation. This is material-specific and must be
adapted for correct measurement results.
Non-metals (paper, ceramic, gypsum, wood, paints and
coatings), plastics and food have high emissivity, which means
