6 Using the product
25
4. Move Joystick up/down to set the desired value. Move
Joystick right/left to change between the numbers.
5. Confirm the entry with [OK].
6. Confirm the settings with Apply.
Measuring range
The measuring range can be set to adapt to the respective area
of application.
1. [OK] | Measurement | [OK] | Measurement range.
2. Select the desired temperature range and confirm with
[OK].
Depending on the scene temperature, the measuring
range may be undershot or exceeded. In this case, ---
or +++ are shown instead of the readings.
> If this occurs, change the measuring range.
6.1.2. Image gallery
Show images…
1. [OK] | Image gallery | [OK] | Show images… | [OK].
- The Folder dialogue is opened.
- The folder name of the opened folder is displayed in the
header. ROOT designates the base folder (top level).
- The saved data is shown as preview images (image
overview). The image saved last is shown directly behind
the folders.
Optional:
> Press the right [Page scroll] quick select button to change
to page scroll.
In page scroll, you can navigate in groups of 3 x 3
images/folders (page by page). To select/open an
image/folder, you must change back into Single Image.
2. Navigate:
• In page scroll: Move Joystick up/down to change
between the pages.
• In single image: Move Joystick up/down/left/right to
select a preview image/a folder (orange border).
• Open selected folder with [OK].
