BQ79600-Q1 Evaluation Module
5 Physical Dimensions
5.1 Board Dimensions
Board dimensions: 2.300 in. × 5.130 in.
Board height:
• Top - Tallest component (shunts) is 0.35 in. (8.8 mm) above PCB.
• Bottom - Tallest component (transformers) is 0.41 in. (10.5 mm) above PCB.
5.2 Board Mounting
Figure 8 illustrates the EVM board dimensions.
Figure 8. Board Dimensions
6 Schematics, Assembly, Layout, and Bill of Materials (BOM)
The BQ79600EVM schematics, assembly, layout, and BOM are provided in their respective sections.
