Schematics, Assembly, Layout, and Bill of Materials (BOM)
www.ti.com
22
SLUUC57A–October 2019–Revised June 2020
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
BQ79600-Q1 Evaluation Module
6.4 Bill of Materials (BOM)
Designator Quantity Value Description PackageReference PartNumber Manufacturer
!PCB1 1 Printed Circuit Board BMS030 Any
C1 1 0.1uF CAP, CERM, 0.1 uF, 50
V, +/- 5%, X7R, 0603
0603 C0603C104J5R
ACTU
Kemet
C2, C3 2 0.22uF CAP, CERM, 0.22 uF,
10 V, +/- 10%, X7R,
0603
0603 C0603C224K8R
ACTU
Kemet
C4 1 0.1uF CAP, CERM, 0.1 uF, 10
V, +/- 10%, X7R, AEC-
Q200 Grade 1, 0402
0402 GCM155R71A1
04KA55D
MuRata
C7, C8, C9,
C10, C11, C12
6 100pF CAP, CERM, 100 pF, 50
V,+/- 5%, C0G/NP0,
AEC-Q200 Grade 1,
0603
0603 GCM1885C1H1
01JA16J
MuRata
D2 1 Green LED, Green, SMD LED_0805 LTST-
C170KGKT
Lite-On
D3 1 Red LED, Red, SMD Red 0805 LED LTST-
C170KRKT
Lite-On
D4, D5 2 28V Clamp 13A
(8/20µs) Ipp Tvs Diode
Surface Mount TO-
236AB
SOT23-3 PESD5V0L2BT,
215
Nexperia
H1, H2, H3 3 Machine Screw, Round,
#4-40 x 1/4, Nylon,
Philips panhead
Screw NY PMS 440
0025 PH
B&F Fastener
Supply
H4, H5, H6 3 Standoff, Hex, 0.5"L #4-
40 Nylon
Standoff 1902C Keystone
H7, H8 2 Rectangular Housing
Connector, 4 Pos,
2.54mm
50-57-9404 Molex
J1, J3, J6, J10,
J11, J12
6 Header, 100mil, 3x1, TH Header, 3x1, 100mil,
TH
800-10-003-10-
001000
Mill-Max
J2 1 Header, 0.5mm, 6x1,
R/A, Gold, TH
Header, 0.5mm, 6x1,
R/A, TH
22-12-4062 Molex
J4 1 CONN HEADER 10POS
.100 DL R/A AU
HDR10 TSW-105-08-L-
D-RA
Samtec
J5, J8, J13 3 Header, 2.54mm, 1x2,
Tin, Black, TH
Header, 2.54mm,
2x1, TH
PEC01DAAN Sullins Connector
Solutions
J7, J9 2 Receptacle, 2.54mm,
10x2, Tin, TH
Receptacle, 2.54mm,
10x2, TH
SSQ-110-03-T-
D
Samtec
J14, J15 2 Header(shrouded),
2.54mm, 4x1, R/A,
Gold, TH
Header(shrouded),
2.54mm, 4x1, R/A,
TH
70551-0038 Molex
J16, J17 2 Header, 100mil, 2x1,
Tin, TH
Header, 2 PIN,
100mil, Tin
PEC02SAAN Sullins Connector
Solutions
J18, J19 2 Header, 100mil, 3x1,
Tin, TH
Header, 3 PIN,
100mil, Tin
PEC03SAAN Sullins Connector
Solutions
LBL1 1 Thermal Transfer
Printable Labels, 0.650"
W x 0.200" H - 10,000
per roll
PCB Label 0.650 x
0.200 inch
THT-14-423-10 Brady
Q1 1 20V MOSFET, N-CH, 20 V,
0.2 A, AEC-Q101, SC-
89
SC-89 RE1C002UNTC
L
Rohm
R1 1 10 RES, 10, 5%, 0.1 W,
AEC-Q200 Grade 0,
0603
0603 CRCW060310R
0JNEA
Vishay-Dale
To Next Page
