Texas Instruments LMK04826 User Manual

www.ti.com Bill of Materials for LMK0482x
47
SNAU145B–MAY 2013–Revised March 2018
Submit Documentation Feedback
Copyright © 2013–2018, Texas Instruments Incorporated
Bill of Materials
Table 8. Bill of Materials LMK0482x Evaluation Boards (continued)
ITEM DESIGNATOR DESCRIPTION MANUFACTURER PART NUMBER QTY.
34
R62, R381 RES, 4.70k ohm, 1%,
0.1W, 0603
Yageo America RC0603FR-074K7L
2
35
R63, R64, R66, R67,
R70, R73, R88, R89,
R91, R92
RES, 560 ohm, 5%,
0.1W, 0603
Vishay-Dale CRCW0603560RJNEA
10
36
R81, R94, R312, R315,
R317, R318, R321,
R324
RES, 15k ohm, 5%,
0.1W, 0603
Vishay-Dale CRCW060315K0JNEA
8
37
R83, R85 RES, 270 ohm, 5%,
0.1W, 0603
Vishay-Dale CRCW0603270RJNEA
2
38
R100, R101, R105,
R106, R107
RES, 0 ohm, 5%,
0.063W, 0402
Vishay-Dale CRCW04020000Z0ED
5
39
R103, R104, R111,
R112, R125, R126,
R133, R134, R231,
R232
RES, 240 ohm, 5%,
0.1W, 0603
Vishay-Dale CRCW0603240RJNEA
10
40
R333, R341 FB, 120 ohm, 500 mA,
0402
TDK MMZ1005Y121C
2
41
R350, R360, R369 RES, 51k ohm, 5%,
0.1W, 0603
Vishay-Dale CRCW060351K0JNEA
3
42
R351 RES, 2.00k ohm, 1%,
0.1W, 0603
Vishay-Dale CRCW06032K00FKEA
1
43
R356 RES, 866 ohm, 1%,
0.1W, 0603
Vishay-Dale CRCW0603866RFKEA
1
44 S1, S2, S3, S4, S5, S6 0.375" Standoff VOLTREX SPCS-6 6
45
SPI Low Profile Vertical
Header 2x5 0.100"
FCI 52601-G10-8LF
1
46 U1
LMK04826
Texas Instruments
LMK04826BISQ
1
LMK04828 LMK04828BISQ
47 U2 122.88 MHz VCXO Crystek CVHD-950-122.88 1
48
U302 Micropower 800mA Low
Noise "Ceramic Stable"
Adjustable Voltage
Regulator for 1V to 5V
Applications, 8-pin LLP,
Pb-Free
Texas Instruments LP3878SD-ADJ/NOPB
1
49
U303, U305 Ultra Low Noise, 150mA
Linear Regulator for
RF/Analog Circuits
Requires No Bypass
Capacitor, 6-pin LLP,
Pb-Free
Texas Instruments LP5900SD-3.3/NOPB
2
50 Vcc Connector, TH, SMA Emerson Network Power 142-0701-201 1
