Jumper J4
Open to disconnect LED
Orient Pin 1 of
MSP430 device
Jumper J5
Open to measure current
Connector J3
External power connector
Remove R8 and jumper R9
LED connected to P1.0
Schematics and PCBs
Figure B-6. MSP-TS430DW28 Target Socket Module, PCB
