www.ti.com

LED connected

to P1.0

Connector J5

External power connector

Jumper JP1 to 'ext'

Jumper JP3

Open to disconnect LED

Jumper JP2

Open to measure current

Schematics and PCBs

Figure B-10. MSP-TS430QFN23x0 Target Socket Module, PCB

SLAU138F – June 2004 – Revised March 2007 Hardware 47

Submit Documentation Feedback
