Orient pin 1 of
MSP430 device
LED connected to P1.0
Connector J3
External power connector
Jumper JP1 to 'ext'
Jumper JP3
Open to disconnect LED
Jumper JP2
Open to measure current
Jumpers JP4 to JP9
Close 1-2 to debug in
Spy-Bi-Wire Mode,
Close 2-3 to debug in
4-wire JTAG Mode
Schematics and PCBs
Figure B-8. MSP-TS430DA38 Target Socket Module, PCB
Note: See Section A.1 , note 2.
SLAU138F – June 2004 – Revised March 2007 Hardware 45
