www.ti.com
Jumper J4
Open to
disconnect LED
LED connected
to P1.0
Orient pin 1 of
MSP430 device
Jumper J5
Open to measure current
Connector J3
External power connector
Jumper JP1 to ‘ext’
Schematics and PCBs
Figure B-12. MSP-TS430DL48 Target Socket Module, PCB
SLAU138F – June 2004 – Revised March 2007 Hardware 49
Submit Documentation Feedback
