Texas Instruments MSP Series - MSP-TS430 PM64 Target Socket Module, PCB

www.ti.com
Connector J5
External power connection
Remove R8 and jumper R9
LED connected
to pin 12
Jumper J6
Open to disconnect LED
Jumper J7
Open to measure current
Orient Pin 1 of
MSP430 device
Schematics and PCBs
Figure B-14. MSP-TS430PM64 Target Socket Module, PCB
SLAU138F – June 2004 – Revised March 2007 Hardware 51
