Texas Instruments Tiva TM4C123GH6PM User Manual

Analog to Digital Converter (ADC)
void ROM_ADCPhaseDelaySet (uint32_t ui32Base, uint32_t ui32Phase)
void ROM_ADCProcessorTrigger (uint32_t ui32Base, uint32_t ui32SequenceNum)
uint32_t ROM_ADCReferenceGet (uint32_t ui32Base)
void ROM_ADCReferenceSet (uint32_t ui32Base, uint32_t ui32Ref)
void ROM_ADCSequenceConfigure (uint32_t ui32Base, uint32_t ui32SequenceNum, uint32_t
ui32Trigger, uint32_t ui32Priority)
int32_t ROM_ADCSequenceDataGet (uint32_t ui32Base, uint32_t ui32SequenceNum,
uint32_t ∗pui32Buffer)
void ROM_ADCSequenceDisable (uint32_t ui32Base, uint32_t ui32SequenceNum)
void ROM_ADCSequenceEnable (uint32_t ui32Base, uint32_t ui32SequenceNum)
int32_t ROM_ADCSequenceOverflow (uint32_t ui32Base, uint32_t ui32SequenceNum)
void ROM_ADCSequenceOverflowClear (uint32_t ui32Base, uint32_t ui32SequenceNum)
void ROM_ADCSequenceStepConfigure (uint32_t ui32Base, uint32_t ui32SequenceNum,
uint32_t ui32Step, uint32_t ui32Config)
int32_t ROM_ADCSequenceUnderflow (uint32_t ui32Base, uint32_t ui32SequenceNum)
void ROM_ADCSequenceUnderflowClear (uint32_t ui32Base, uint32_t ui32SequenceNum)
5.2.1 Function Documentation
5.2.1.1 ROM_ADCComparatorConfigure
Configures an ADC digital comparator.
Prototype:
void
ROM_ADCComparatorConfigure(uint32_t ui32Base,
uint32_t ui32Comp,
uint32_t ui32Config)
ROM Location:
ROM_APITABLE is an array of pointers located at 0x0100.0010.
ROM_ADCTABLE is an array of pointers located at ROM_APITABLE[5].
ROM_ADCComparatorConfigure is a function pointer located at ROM_ADCTABLE[15].
Parameters:
ui32Base is the base address of the ADC module.
ui32Comp is the index of the comparator to configure.
ui32Config is the configuration of the comparator.
Description:
This function will configure a comparator. The ui32Config parameter is the result of a logical
OR operation between the ADC_COMP_TRIG_xxx, and ADC_COMP_INT_xxx values.
The ADC_COMP_TRIG_xxx term can take on the following values:
ADC_COMP_TRIG_NONE to never trigger PWM fault condition.
ADC_COMP_TRIG_LOW_ALWAYS to always trigger PWM fault condition when ADC out-
put is in the low-band.
ADC_COMP_TRIG_LOW_ONCE to trigger PWM fault condition once when ADC output
transitions into the low-band.
36 April 8, 2013

Texas Instruments Tiva TM4C123GH6PM Specifications

General

Core	ARM Cortex-M4F
Clock Speed	80 MHz
Flash Memory	256 KB
SRAM	32 KB
GPIO Pins	43
UART	8
I2C	2
SPI/SSI	4
USB	USB 2.0
Timers	6
Communication Interfaces	UART, I2C, SPI, USB
Operating Temperature	-40°C to 85°C
Package	LQFP64

Summary

Boot Loader

Introduction

Explains the ROM-based boot loader and its interfaces for flash updates.

Serial Interfaces

Details the UART, SSI, and I2C interfaces used by the boot loader.

USB Interface

Describes the USB boot loader functionality using the DFU protocol.

Controller Area Network (CAN)

Flash

GPIO

Hibernation Module

Inter-Integrated Circuit (I2C)

Interrupt Controller (NVIC)

Memory Protection Unit (MPU)

Pulse Width Modulator (PWM)

Synchronous Serial Interface (SSI)

System Control

Timer

UART

uDMA Controller

USB Controller

Using USB with the uDMA Controller

Watchdog Timer

Introduction

Functions

Lists and describes API functions for watchdog timer configuration, interrupts, and lock mechanism.
