Texas Instruments TMS320C6455 User Guide

DDR2 Memory Controller Registers www.ti.com
4.8 DDR2 Memory Controller Control Register (DMCCTL)
The DDR2 memory controller control register (DMCCTL) resets the interface logic of the DDR2 memory
controller. The DMCCTL is shown in Figure 26 and described in Table 25.
Figure 26. DDR2 Memory Controller Control Register (DMCCTL)
31 16
Reserved
R-0x5000
15 6 5 4 3 2 0
IF
Reserved Rsvd Rsvd RL
RESET
R/W-0x0190 R/W- R/W- R-0x0 R/W-0x7
0x1 0x0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 25. DDR2 Memory Controller Control Register (DMCCTL) Field Descriptions
Bit Field Value Description
31-6 Reserved Reserved. Writes to this register must keep this field at its default value.
5 IFRESET DDR2 memory controller interface logic reset. The interface logic controls the signals used to
communicate with DDR2 SDRAM devices. This bit resets the interface logic. The status of this
interface logic is shown on the DDR2 memory controller status register.
0 Release reset.
1 Assert reset.
4 Reserved Reserved. Writes to this register must keep this field at its default value.
3 Reserved Reserved. The reserved bit location is always read as 0. A value written to this field has no effect.
2-0 RL Read latency bits. These bits must be set equal to the CAS latency + 1.
48
C6455/C6454 DDR2 Memory Controller SPRU970G– December 2005– Revised June 2011
Submit Documentation Feedback
Copyright © 2005–2011, Texas Instruments Incorporated
