Chapter 2
SPNU597–May 2014
Physical Description
This section describes the physical layout of the TMS570LC43 HDK board and its interfaces.
2.1 Board Layout
The TMS570LC43 HDK board is a 4.9 x 4.3 inch (125 x 109 mm) eight layer printed circuit board that is
powered by an external +5 V to approximately +12 V only power supply. Figure 2-1 shows the layout of
the TMS570LC43 HDK board.
Figure 2-1. TMS570LC43 HDK Board, Interfaces Top Side
