INS877-4 13/26
2.2 Magnet mounting (type SC only)
Once the device has been mounted, position the magnet so the notch is
aligned with the arrow marker on the PCB.
The magnet can be installed on either side of the device. Greater sensitivity
is achieved by positioning the magnet so the notch is aligned with the arrow
(see figure 4 for magnet distances).
Figure 4
