5
BZT 2000
Series
4. TRACTION LEVERS
a) Remove bolt A.
b) Rotate traction lever B into position and secure
with bolt A. Repeat for the other lever.
c) Tighten all fasteners.
d) Sit on the machine. If the levers are too long,
bracket C may be removed to make them
shorter.
5. FINAL PREPARATIONS
– Check the engine and hydraulic oil levels. Top up with the correct oil if necessary. Use 10W30 motor oil
for the engine. Use fresh, clean 15W40 or 20W50 motor oil or 15W50 synthetic motor oil for the hydraulic
system.
– Remove the battery from the machine.Fill the battery to the bottom of the vent wells with acid and trickle
charge for several hours. Replace the battery in the machine and make the connections, red to positive
first, then black (ground) to negative.
– Read Operation and Safety Manual before starting.
– Run engine at full RPM for 5 minutes before engaging blades to allow the engine to be fully lubricated
before load is applied.
– Check the hydrostat neutral adjustment. Neutral is set at the factory but may require readjustment if air
trapped during the initial oil fill has worked out of the system. See adjustments section later in this manual.
– Do not use the machine without an approved grass collector, the grass discharge chute or mulching plates
correctly fitted.
ASSEMBLY AND SETUP
