McCAULEYPROPELLERSYSTEMS
CONSTANTSPEEDCOMPOSITEOWNER/OPERATOR
INFORMATIONMANUAL
D-60371
C2616
1.00 Inch
(25.40 mm)
Feed Shoe
9.00 Inches
(228.60 mm)
0.72 to 1.00 Inch
(19.05mm to 25.40 mm)
Radius
DETAIL A
Feed Shoe Trim
A
A
Spinner
Propeller Blade
A
VIEW A-A
Shown with Spinner Removed
Bulkhead Assembly
Propeller Blade
Feed Shoe
PropellerAnti-iceFeedShoes
Figure201(Sheet1)
61-13-45Page205
©McCauleyPropellerSystemsJan9/2017
