8
> Change from previous revision
PGM
Item Part No. Qty. Description Serial Numbers/Notes
●
1
2811557 1 Frame, L.H.
2 337677 1 • Seal, Oil
3 2811124 1 • Stud, Handle
4 336962 1 • Seal, Oil
5 500534 2 • Bearing Cup and Cone
6 545940 2 • Bushing
7 365753 1 • Seal, Grease
8 303490 1 • Bearing
9 307959 1 • Washer
10 446116 1 • Lockwasher, #10 Medium
11 403912 1 • Screw, #10-24 x 5/8” Truss Head
12 2500463 1 • Gear, Internal
13 461165 3 • Pin, 5/32 x 1/2” Groove, Type 1
14 472005 1 Plug, 3/8 Pipe, Headless
◆ 15 434028 1 Screw, 1/4-20 x 3/4” Soc Head
16 446130 1 Lockwasher, 1/4 Heavy
17 106790 1 Guide, Chain
18 325654 1 Collar
19 461173 1 Pin, 5/32 x 1” Groove, Type 1
20 503448 1 Sprocket, Reel
21 304743 1 • Bushing
22 304745 1 Washer
23 304746 1 Clutch, Reel
24 463113 2 Key, 3/4 x 3/16 Morton
25 1004944 1 Guide, Chain
26 2500020 1 Planetary Gear Set Spider
27 463017 1 Key, Woodruff #9
28 415007 1 Screw, 5/16-18 x 3/8” Set , Soc Hd
29 428511 1 Screw, 5/16-18 x 5/16” Set , Soc Hd
30 2500024 3 Pinion, Idler
31 304718 3 • Bushing
32 131832 1 Drive Pinion and Socket
33 304730 1 • Bushing
34 307374 AR Washer, Thrust
35 458013 1 Ring, Retaining
36 364079 1 Chain, Reel to Traction Shaft
37 500326 1 Chain, PTO to Reel
470503 1 • Link, Chain
38 453023 1 Washer, 1/4 Flat
39 306828 AR Washer, Thrust
40 471214 1 Fitting, Grease
Required for proper sealing of Left Side Frame
● 473194 AR Loctite Primer 6 oz Aerosol Can
◆ 473130 AR Loctite 242 (Blue)
To Next Page
