10
> Change from previous revision
PGM
Item Part No. Qty. Description Serial Numbers/Notes
1
2811558 1 Frame, R.H.
2 337677 1 • Seal, Oil
3 336962 1 • Seal, Oil
4 500534 2 • Bearing Cup and Cone
5 2811124 1 • Stud, Handle
6 545940 1 • Bushing
7 307377 1 Spacer, Shaft
8 471223 1 Fitting, Grease
9 471214 1 Fitting, Grease
10 363047 1 Spring, Tension
11 453020 1 Flat Washer, 5/8
12 444713 1 Locknut, 5/8-16 Center Jam
13 304747 2 Gasket
14 348847 1 Cover, Reel Bearing
15 446130 4 Lockwasher, 1/4 Heavy
16 434028 4 Screw, 1/4-20 x 3/4” Socket Hd
◆ 17 434041 4 Screw, 1/4-20 x 3/4” Flat Socket Hd
18 1001308 1 Bracket, R.H. Brake Mounting
19 3002907.7 1 Housing, Bearing
20 343667 1 Bearing, Ball
21 445798 1 Locknut, 3/4-16 Stover
◆ 473130 AR Loctite 242 (Blue)
To Next Page
