12
> Change from previous revision
PGM
Item Part No. Qty. Description Serial Numbers/Notes
●▲
1
122544 1 Cross Bar, Front
2 122545 1 Cross Bar, Rear
3 400266 8 Screw, 3/8-16 x 1-1/2”
4 446142 8 Lockwasher, 3/8 Heavy
5 304740 1 Tie Rod, Front
6 443114 2 Nut, 7/16-14 Hex
7 446148 2 Lockwasher, 7/16
8 363328 1 Strap, Grass Shield
9 343732 1 Bracket, Support
10 5002605 1 Reel, 22” 11 Blade
11 400106 1 Screw, 1/4-20 x 5/8” Hex Head
12 348849 AR Shim
13 446130 1 Lockwasher, 1/4 Heavy
14 4139463 1 Shield, Grass
15 500627 1 Shoe, Bedknife
15 4130298 1 Bedknife Backing, PGM MagKnife Optional MagKnife
16 446136 4 Lockwasher, 5/16 Heavy
17 443112 2 Nut, 3/8-24 Hex
18 See Chart 1 Bedknife
19 3009138 13 Screw, 1/4-20 x 1/2” Flat Head
20 365502 1 Screw, L.H. Bedknife Mounting Apply Never Sieze to bolt
21 365501 1 Screw, R.H. Bedknife Mounting Apply Never Sieze to bolt
22 454017 2 Washer, Shakeproof Cone
23 332516 2 Rod, Bedknife Adjusting
24 307456 4 Cup, Bedknife Adjusting Spring
25 307360 2 Spring, Bedknife Adjusting
26 350626 4 Nut, Bedknife Adjusting
27 307373 1 Support, Spring
28 343616 2 Stud
29 3005692 2 Nut, Roller Adjusting
30 400184 2 Screw, 5/16-18 x 3/4” Hex Head
31 3008438 1 Bracket, R.H. Roller
32 103399 1 Support Rod and Foot Rest
33 3008439 1 Bracket, L.H. Roller
34 441677 2 Bolt, 5/16-18 x 1-1/2” Carriage
35 452006 2 Washer, 5/16 Flat
36 NS 1 Plate, Serial
37 443106 2 Nut, 5/16-18 Hex
38 352737 2 Screw, 1/4-20 x 7/8” Set, Sq Head
39 443102 3 Nut, 1/4-20 Hex
40 461181 1 Pin, 3/16 x 3/4” Groove
Required for proper sealing of Left Side Frame
● 473194 AR Loctite Primer 6 oz Aerosol Can
▲ 473195 AR Loctite 518 Gasket Eliminator 15 oz cartridge
To Next Page
