13
OPERATION section 4.8
Belt Size Chart for Steiner Tractors and Attachments
Model Description 425
without electric clutch
*Part No.
425
with electric clutch
*Part No.
Engine Drive Pulley to Idler 81-B042 81-B041
BM425 Boom Mower 81-B041 or 81-A040 81-B040
All Rotary Mowers 81-B041 or 81-A040 81-B040
PB100 Power Blower 81-B041 or 81-A040 81-B040
RM674 Reel Mower 81-B044 or 81-A043 81-B043
RS350 Rotary Sweeper 81-B041 or 81-A040 81-B040
SB348 Snowblower 81-B054 or 81-A053 81-B053
SC101 Stump Cutter 81-B045 or 81-A044 81-B044
TL348 Tiller 81-B041 or 81-A040 81-B040
* See attachment Parts Manual for correct belt part numbers.
Use only Steiner approved belts.
Photo 4B - Electric Clutch Access Door
TIRE BAL LAST
Liquid, foam, rubber or powder ballast in
tires causes excess loads on the drive train and
WILL VOID WARRANTY ON THE DRIVE TRAIN
COMPONENTS of the power unit. Modified or
makeshift weights are not acceptable.
Rear weights must be used with attachments
over 120 pounds for stability. See attachment
operator's manual for weight requirements.
Always remove all rear weights when front
mounted attachments are removed, or when
using attachments less than 120 pounds, to
reduce the danger of unit tipping over backward
while climbing steep slopes or loading ramps.
