Textron Steiner 425 - Rear Weight Bar Attachment Figure 17

B-2
1 42-467 Weight Security Rod 1
2 62-540 Weight 55# 4
3 02-PP0524 Presto Pin, 5/32 1
4 62-542 Drawbar Hitch Extension 1
5 62-541 Tractor Weight Bar 1
6 64-474 Mounting Bracket (425 only) 1
7 64-473 Drawbar Attaching Plate (425 only) 1
8 90-1012 Bolt, 5/8 x 1-1/2 2
9 96-10 Lock Washer, 5/8 2
10 92-10 Nut, 5/8 2
11 90-0810 Bolt, 1/2 x 1-1/4 4
12 96-08 Lock Washer, 1/2 4
13 92-08 Nut, 1/2 4
14 90-0608 Bolt, 3/8 x 1 2
15 99-E13 Flange Nut, 3/8 2
PARTS appendix B-2
Parts List for Figure 17
Ref Part no. De scrip tion Quan tity
Rear Weight Bar
Attachment
Figure 17
