B-3
SAFETY
Weights must be used with some rear mounted attachments for stability.
Weights must be removed when rear mounted attachments are removed.
Always use security rod to hold weights in position.
WEIGHTS appendix B-3
FRONT WEIGHT INSTRUCTIONS
Weights are added to the front of the tractor to provide counter balance for 3-point hitch mounted
equipment. Always add enough weight to provide stability. This will vary with the weight of the rear
mounted implement.
1. Attach the front weight frame to the front lift quick hitch in the usual manner.
2. Add weights to the weight bar.
3. Install security rod and clip pin.
4. Remove weights when the rear mounted implement is removed.
To Next Page
