6.2.5 OPERATOR STATION PANELS
The operator stations are all equipped with the same monitor movement functions. From the operator stations, the operator can
command the monitor up, down, left, right and command the nozzle pattern shaper from fog to straight stream. Operator stations
supplied with the membrane switch, shown on the left below, allow the operator to program and perform the oscillate and stow features.
Fig 6.2.5
Operator Station Button Layouts
6.2.6 OVERRIDE KNOBS
In the event of electrical system failure on the monitor or fire apparatus, the Tornado RC
Monitor is factory supplied with override knobs so the monitor may be manually operated.
If desirable, the override knobs may be removed. The drive shafts have a hex so a
wrench or socket may be used for manual override. The wrenching hexes are shown in
figure 6.2.3.
Fig 6.2.3
Wrenching Hexes on Drive Shafts
6.3 RECOMMENDED STOWING POSITION
For truck mounted applications, it is recommended that the monitor be stowed in a
position such that the monitor's nozzle rests against a bracket or support surface. This
will minimize bouncing of the nozzle when the apparatus is traveling. Always be sure
the monitor is properly stowed before moving the truck and know the overall
height to avoid damage from overhead obstructions such as doors or bridges.
11/16”
(18 mm)
HEX
6.4 FLOWS AND PRESSURES
6.4.1 STACKED TIPS FLOW
NOZZLE INLET PRESSURE
NOZZLE
DIAMETER
FLOW
(L/min)
FLOW
(L/min)
FLOW
(L/min)
FLOW
(L/min)
FLOW
(L/min)
REACTION
(KG)
REACTION
(KG)
REACTION
(KG)
REACTION
(KG)
REACTION
(KG)
4 BAR 6 BAR 8 BAR 10 BAR
NOZZLE INLET PRESSURE
NOZZLE
DIAMETER
1.0 INCH
1-1/4 INCH
1-1/2 INCH
FLOW
(GPM)
FLOW
(GPM)
FLOW
(GPM)
FLOW
(GPM)
FLOW
(GPM)
REACTION
(LBS)
REACTION
(LBS)
REACTION
(LBS)
REACTION
(LBS)
REACTION
(LBS)
210
330
470
270
410
—
300
460
—
360
—
—
390
—
—
80
120
170
120
190
—
150
230
—
230
—
—
260
—
—
50 PSI 80 PSI 100 PSI 150 PSI 175 PSI
12 BAR
FLOW EXCEEDS RATING OF TORNADO MONITOR
Fig 6.4.1
Stacked Tips Flow Table
25 MM
32 MM
38 MM
830
1300
1900
1000
1700
—
1200
1900
—
1300
—
—
1400
—
—
40
70
90
60
100
—
80
130
—
100
—
—
120
—
—
