Audio Codec Adapter Setup for Cinterion
®
Modules
1 Introduction
33
audio_codec_adapter_setup_v04 2019-10-16
Confidential / Released
Page 5 of 34
1 Introduction
The Audio Codec Adapter is a simple and easy-to-use universal adapter board designed to
quickly evaluate the digital audio functionality of the supported Gemalto M2M (evaluation)
products. Using this reference adapter, it is possible to develop and test external audio appli-
cations for the supported Cinterion
®
modules (see Section 1.2).
This document
1
guides you through the process of connecting the Audio Codec Adapter cor-
rectly and getting started with the evaluation of the module’s audio functionality.
The Audio Codec Adapter is intended for use in test environments only. All persons handling
the Audio Codec Adapter must be properly trained in electronics and observe good engineering
practice standards.
The Audio Codec Adapter is a test/development board, and has not been designed to be em-
bedded into other products.
1.1 Related Documents
[1] AT Command Set for your product
[2] Hardware Interface Description for your product
[3] DSB75 Hardware Description, v14
[4] Getting Started with your product
1.2 Supported Products
This User Guide applies to the following products:
• AGS2-E, AGS2-W
• BGS2-E, BGS2-W
• BGS5, BGS8
• EHS5-E, EHS5-US, EHS6, EHS8
• ELS31-VA
• ELS61-E, ELS61-E2, ELS61-ER2, ELS61-US, ELS61-AUS, ELS81-E, ELS81-US
• PDS5, PDS6, PDS8
• AHS3-E, AHS3-W
• PHS8-P, PHS8-E, PHS8-US, PHS8-USA
• ALS3-E, ALS3-US, ALS3-C
• PLS8-E, PLS8-US, PLS8-V, PLS8-X, PLS8-J
•ALAS5
1.
The document is effective only if listed in the appropriate Release Notes as part of the technical docu-
mentation delivered with your Gemalto M2M module.
