The application programmes RAMSES 718 P/S
RAMSES 718 P / RAMSES 718 S 33
4.4 Parameter pages overview
The device consists of one general block and 4 main functional blocks.
Parameter page
Description
General functional block
General
LED settings, activation of the temperature sensor inputs.
Measurement values
Setting for temperature measurement (internal sensor)
RTC functional block
Setting
General settings to operate
9
and temperature control
Actual value
Source for actual value measurement, actual value monitoring, etc.
Operating Mode
Operating mode after reset, presence sensor etc.
Heating control
Control parameters, installation type etc. for heating mode.
Heating set points
Base set point value, lowering, frost protection etc.
Additional stage
heating
Type of actuating value, proportional band, transmission behaviour.
Cooling control
Control parameters, installation type etc. for cooling mode.
Cooling set points
Dead zone, standby, heat protection etc.
set point adjustment
Setting maximum adjustment.
Additional stage
cooling
Type of actuating value, proportional band, transmission behaviour.
External inputs functional block
Channel I1
Function of the input, debounce time, number of telegrams, block
function, etc.
Additionally at I3 and I4: Selection of the temperature sensor,
temperature calibration, etc.
Channel I2
Channel I3
Channel I4
Switch object 1
Object type, transmission behaviour, etc. can be set for each object
individually.
Switch object 2
Switch object 3
Button object 1
Object type, transmission behaviour, etc. can be set for each object
individually.
Button object 2
Button object 3
Dimming
Type of control
Blinds
Type of control
Double-click
Additional telegrams for dimming and blinds
9
Only RAMSES 718 P

Theben KNX Series Specifications

General

Communication Protocol	KNX
Ambient Temperature	-5°C to +45°C
Storage Temperature	-25°C to +70°C
Protection Class	IP20
Relative Humidity	5% to 95%, non-condensing
Operating Voltage	24 V DC (via KNX bus)
