Theben KNX Series User Manual

The application programmes RAMSES 718 P/S
RAMSES 718 P / RAMSES 718 S 55
4.7 External inputs I1-I4 functional block
4.7.1 Switch function
Designation
Values
Description
Activate channel
no
yes
Use input?
Channel function
Switch..
Push button..
Dimming..
Blinds..
Sends, depending on whether
the input is 0 or 1.
Debounce time
30 ms, 50 ms, 80 ms
100 ms, 200 ms,
1 s , 5 s, 10 s
In order to avoid a disruptive
switching due to debouncing of
the contact connected to the
input, the new status of the input
is only accepted after a delay
time.
Larger values (≥ 1s) can be used
as a switch-on delay
Send cyclically
every min
every 2 min.
every 3 min.
…
every 30 min.
every 45 min.
every 60 min.
Common cycle time for all 3
initial objects of the channel.
Number of telegrams
one telegram
two telegrams
three telegrams
Each channel has 3 initial objects
and can thus send up to 3
different telegrams.
Activate block function
no
No block function.
yes
Show block function parameter
page.
Block telegram
Block with 1 (standard)
0 = enable
1 = block
Block with 0
0 = block
1 = enable
