4.6.4 Heating control
Designation
Values
Description
Type of control
Continuous
Infinite control
(0.. 100%).
2-point
Switching control (On/Off).
See in the Appendix: Continuous
and switching control.
Number of heating stages
Only one heating stage
Main stage and
additional stage
Choice of 1- or 2-stage heating
Hysteresis of 2-point controller
0.3 K
0.5 K
0.7K
1 K
1.5 K
Interval between the tripping
point (set point) and the turn
back on point (set point –
hysteresis).
The hysteresis prevents a
permanent switching on/off.
Recirculation of hysteresis after
switching point
None
0.1 K/min
0.2 K/min
0.3 K/min
The recirculation causes a
gradual decrease in the
hysteresis over time, and the
control accuracy is increased.
The hysteresis is equivalent to
the programmed value for each
switch-off and is gradually
reduced by the recirculation
process. The hysteresis can
reduce to 0 K over prolonged
periods of switch-off.
When switching on the next time,
it will be reset to the configured
value.
Setting the control parameters
Via installation type
Standard application.
The control parameters are
preset.
User-defined
Professional use: Configure P/PI
controller yourself.
Installation type
Radiator heating
system
PI controller with:
Integrated time = 90 minutes
Bandwidth = 2.5 K
Underfloor heating
Integrated time = 30 h
Bandwidth = 4 K
Proportional band of heating
controller
1 K, 1.5 K, 2 K, 2.5 K,
3 K, 3.5 K, 4 K, 4.5 K,
5 K, 5.5 K, 6 K, 6.5 K,
7 K, 7.5 K, 8 K, 8.5 K
Professional setting for adapting
control response to the room.
Small values cause large changes
in actuating values, larger values
cause a finer actuating value
adjustment.
See in the Appendix:
Temperature control

Theben KNX Series Specifications

General

Communication Protocol	KNX
Ambient Temperature	-5°C to +45°C
Storage Temperature	-25°C to +70°C
Protection Class	IP20
Relative Humidity	5% to 95%, non-condensing
Operating Voltage	24 V DC (via KNX bus)
