Theben KNX Series User Manual

The application programmes RAMSES 718 P/S
RAMSES 718 P / RAMSES 718 S 60
Designation
Values
Description
Telegram
See above: Same object type as
with short operation.
Send cyclically
no
yes
The cycle time is set on the main
parameter page of the channel.
Response after
restoration of the bus
supply
none
Do not send.
As with short (immediately)
As with short (after 5 s)
As with short (after 10 s)
As with short (after 15 s)
As with long (immediately)
As with long (after 5 s)
As with long (after 10 s)
As with long (after 15 s)
As with double-click (immediately)
As with double-click (after 5 s)
As with double-click (after 10 s)
As with double-click (after 15 s)
Send update telegram
immediately or with delay.
The value to be sent depends on
the value configured for long,
short button push, or double-
click.
Response when setting
the block
Ignore block
The block function is ineffective
with this telegram.
no response
Do not respond when setting the
block.
as with short
Respond as with a short button
push.
as with long
Respond as with a long button
push.
as with double-click
Respond as with a double-click.
Response when
cancelling the block
no response
Do not respond when the block is
cancelled.
as with short
Respond as with a short button
push.
as with long
Respond as with a long button
push.
as with double-click
Respond as with a double-click.
Note: If a channel is blocked, no telegrams will be sent cyclically.
