The application programmes RAMSES 718 P/S
RAMSES 718 P / RAMSES 718 S 70
4.7.5 Temperature sensor function (only I3 and I4)
 The external inputs I3 and I4 can be used as analogue inputs for temperature
measurement via remote sensor.
This function is activated on the General parameter page with the parameter function of the
external inputs I3 + I4.
The temperature measured at I3 can be used internally as an actual value for the RTC
(see Source for actual value parameter).
The temperature measured at I4 can be used internally as a floor temperature for the RTC. See
parameter Use floor temperature limitation (sensor at I4) on the Settings parameter page).
Notwithstanding the above, both measurement values can also be sent to the bus.
Designation
Values
Description
Activate channel
no
yes
Use input?
Sensor type
Remote sensor 1
(9070191)
External temperature sensor 1
Item no. 9070191,
for surface-mounted installation.
Remote sensor IP 65
(9070459)
External temperature sensor
RAMSES IP65
Item no. 9070459,
for surface-mounted installation.
Floor sensor (9070321)
Only at input I4:
Temperature sensor for laying in
floor, IP65 protection rating.
Temperature calibration
-64..+64
(x 0.1 K)
Correction value for temperature
measurement if sent
temperature deviates from the
actual ambient temperature.
Example: Temperature = 20°C
sent temperature = 21°C
Correction value = 10
(d.h. 10 x 0.1°C)
Transmit temperature in the
event of change of
not due to a change
Only send cyclically
(if enabled)
0.2 K
0.3 K
0.5 K
0.7 K
1 K
1.5 K
2 K
Send if the value has changed by
the selected amount since the
last transmission.
