Thecus N7700 User Manual

This screenshot lists iSCSI target volumes created under thin-provisioning. The 2
nd
iSCSI target volume under thin-provisioning has been created with a capacity of
14300GB.
This message appears if there is no more room for new iSCSI target creation.
iSCSI LUN ID
3. The notification will send out while the physical size of iSCSI
thin-provision capacity has used up to 90%.
2. Each thin-provision volume can only create 5 iSCSI target volumes.
1. Each RAID volume can only create one iSCSI thin-provision volume.
NOTE
When iSCSI target volume has been created, there is a default LUN ID of 0 in
previous firmware versions which was un-configurable. From v3.00.04, it is
configurable from 1 to 254 with a default of the next available number in ascending
numerical order. The LUN ID is unique and can not be duplicated except for LUN ID
0.
126

Thecus N7700 Specifications

General

RAID levels	0, 1, 5, 6, 10, JBOD
Storage drive size	3.5 \
Storage drive capacity	- GB
Storage drive interface	Serial ATA
Total installed storage capacity	14 TB
Number of storage drives installed	0
Number of storage drives supported	7
Flash memory	128 MB
Internal memory	2 GB
Internal memory type	DDR2
Processor frequency	1.86 GHz
iSCSI support	Yes
Supported network protocols	SMB/CIFS, HTTP/HTTPS, FTP, NFS v3, AFP
Compliance industry standards	802.3ad
USB 2.0 ports quantity	4
Ethernet LAN (RJ-45) ports	2
Dimensions (WxDxH)	210 x 270 x 320 mm
Management platform	Linux
Compatible operating systems	Windows 7/2000/XP/2003/Vista UNIX/Linux Mac OS 9 / X
Power supply unit (PSU) capacity	300 W
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	0 - 80 %

Weight and Dimensions

Weight	8600 g
