Thecus N7700 User Manual

RAID
6
X X [ONLINE]
[RAID 6] HDDx4 to [RAID 6] HDDx5
[RAID 6] HDDx4 to [RAID 6] HDDx6
[RAID 6] HDDx4 to [RAID 6] HDDx7
[RAID 6] HDDx5 to [RAID 6] HDDx6
[RAID 6] HDDx5 to [RAID 6] HDDx7
[RAID 6] HDDx6 to [RAID 6] HDDx7
Space Allocation
You may specify the space allocated for iSCSI volumes. The iSCSI volume can be
created up to 5 volumes per RAID volume.
To do this, under the Storage menu, click RAID and the RAID List window
appears. Select the RAID volume you wish to reallocate by clicking on its radio
button, and click Space Allocation. The RAID Information and Volume
Allocation List windows will appear.
The Volume Allocation List displays the space allocated for iSCSI volumes on the
current RAID volume. The N7700 supports up to five iSCSI volumes.
Volume Allocation List
Item Description
Modify Click this to modify the allocated space.
Delete Click this to delete the allocated space.
iSCSI Target Click to allocate space to iSCSI volume.
Type Type of volume. Can be either USB or iSCSI.
Name Name assigned to the volume.
Capacity Capacity of the allocated space.
60

Thecus N7700 Specifications

General

RAID levels	0, 1, 5, 6, 10, JBOD
Storage drive size	3.5 \
Storage drive capacity	- GB
Storage drive interface	Serial ATA
Total installed storage capacity	14 TB
Number of storage drives installed	0
Number of storage drives supported	7
Flash memory	128 MB
Internal memory	2 GB
Internal memory type	DDR2
Processor frequency	1.86 GHz
iSCSI support	Yes
Supported network protocols	SMB/CIFS, HTTP/HTTPS, FTP, NFS v3, AFP
Compliance industry standards	802.3ad
USB 2.0 ports quantity	4
Ethernet LAN (RJ-45) ports	2
Dimensions (WxDxH)	210 x 270 x 320 mm
Management platform	Linux
Compatible operating systems	Windows 7/2000/XP/2003/Vista UNIX/Linux Mac OS 9 / X
Power supply unit (PSU) capacity	300 W
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	0 - 80 %

Weight and Dimensions

Weight	8600 g
