Thecus N7700 User Manual

Snapshot
The N7700 is capable for 16 snapshot version control. To have snapshot to work on,
the file system creation for RAID volume has to be “ZFS”.
Snap (Snapshot configuration)
If added folder has located in the RAID volume with “ZFS” file system, then the
folder management screen with “Snap” button will be configurable.
Snapshot
Item Description
Take Shot Click to take snapshot right away.
Remove Click to remove snapshot schedule.
Schedule Click to open snapshot schedule setup screen.
Clicking on schedule button then schedule setup screen appear. Checked the enable
check box to activate the snapshot scheduled operation.
The N7700 snapshot is supported total 16 versions. Once checked “Automatically
remove oldest snapshot”, the oldest will be removed to let newest to added on top.
Otherwise, if the check box is unchecked and snapshot versions are up to 16 then
system will appear warning message and won’t execute the task till available
version count.
The snapshot schedule rules can be setup for monthly, weekly or daily hour.
Clicking on Apply after firmed with desired schedule
69

Thecus N7700 Specifications

General

RAID levels	0, 1, 5, 6, 10, JBOD
Storage drive size	3.5 \
Storage drive capacity	- GB
Storage drive interface	Serial ATA
Total installed storage capacity	14 TB
Number of storage drives installed	0
Number of storage drives supported	7
Flash memory	128 MB
Internal memory	2 GB
Internal memory type	DDR2
Processor frequency	1.86 GHz
iSCSI support	Yes
Supported network protocols	SMB/CIFS, HTTP/HTTPS, FTP, NFS v3, AFP
Compliance industry standards	802.3ad
USB 2.0 ports quantity	4
Ethernet LAN (RJ-45) ports	2
Dimensions (WxDxH)	210 x 270 x 320 mm
Management platform	Linux
Compatible operating systems	Windows 7/2000/XP/2003/Vista UNIX/Linux Mac OS 9 / X
Power supply unit (PSU) capacity	300 W
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	0 - 80 %

Weight and Dimensions

Weight	8600 g
