WAN Configuration
Item Description
Host name Host name that identifies the N7700 on the network.
Domain name Specifies the domain name of the N7700.
WINS Server To set a server name for NetBIOS computer.
MAC Address MAC address of the network interface.
Jumbo Frame Support Enable or disable Jumbo Frame Support of the WAN interface on your
N7700.
IP Sharing Mode When enabled, PCs connected to the LAN port will be able to access the
WAN.
Link Aggregation Specifies whether WAN and LAN ports will be aggregated and act as one
port.
Load Balance: Ethernet traffic will flow alternative between two Ethernet
ports.
Failover: When one port fails, the other one will take over.
802.3ad: Linkage two Ethernet ports in parallel to increase throughput.
Set IP Address by:
Static / Dynamic
You can choose a static IP or Dynamic IP, and input your network
configuration.
IP IP address of the WAN interface.
Netmask Network mask, which is generally: 255.255.255.0
Gateway Default Gateway IP address.
DNS Server Domain Name Service (DNS) server IP address.
NOTE
• Only use Jumbo Frame settings when operating in a Gigabit environment
where all other clients have Jumbo Frame Setting enabled.
• Enabling DHCP automatically turns on UPnP— see the Service Support Screen.
• If you are only using the WAN port, we suggest that you disable IP Sharing
Mode. This will result in higher throughput.
• A correct DNS setting is vital to networks services, such as SMTP and NTP.
• To use the Link Aggregation with “802.3ad selected” feature, please make sure
the networking equipment on the other end of Ethernet cable also supports
802.3ad protocol.
39
