EX-TRAFIRE
®
75SD
Operator Manual, Revision T-57-52
For more detailed information see Service Manual
ERROR CODES
H01 The power input voltage is too low
H02 The power input voltage is too high
H03
System operation failed (e�g�: no arc pressure)
H04 Missing nozzle or electrode
H05
During the pilot arc, the electrode is not separated from the nozzle
(check the electrode free movement)
H06 Over-temperature alarm
H07 Over-current alarm
H08 Torch inspection / cap sensor
H10 Air pressure alarm
H11 Missing phase
H14 Torch trigger is depressed or CNC signal is ON during initial periode
