PARTS LISTS 6-4 Manual 0-2962

6.04 Replacement Parts - for Machine Torches with Unshielded Leads

Item No. Qty Description Catalog No.

1 1 Torch Head Assembly without leads (includes items 2, 3, and 14) 9-8220

2 1 Large O - Ring 8-3487

3 1 Small O - Ring 8-3486

4 1 PIP Switch Kit 9-7036

5 Unshielded Mechanized Leads Assemblies with O2B connectors

1 25 - foot / 7.6 m Leads Assembly with O2B connectors 4-7838*

1 50 - foot / 15.2 m Leads Assembly with O2B connectors 4-7839*

6 Unshielded Automated Leads Assemblies with ATC connectors

1 5 - foot / 1.5 m Leads Assembly with ATC connector 4-7850

1 10 - foot / 3.05 m Leads Assembly with ATC connector 4-7851

1 25 - foot / 7.6 m Leads Assembly with ATC connector 4-7852

1 50 - foot / 15.2 m Leads Assembly with ATC connector 4-7853

7 Unshielded Mechanized Leads Assemblies with ATC connectors

1 5 - foot / 1.5 m Leads Assembly with ATC connector 4-7842

1 10 - foot / 3.05 m Leads Assembly with ATC connector 4-7843

1 25 - foot / 7.6 m Leads Assembly with ATC connector 4-7844

1 50 - foot / 15.2 m Leads Assembly with ATC connector 4-7845

   NN3BDL  

   NN.PVOUJOH5VCF  

10 1 End Cap Assembly 9-7044

11 2 Body, Mounting, Pinch Block 9-4513

12 1 Pin, Mounting, Pinch Block 9-4521

13 1 Torch Holder Sleeve 7-2896

14 1 PIP Plunger and Return Spring Kit 9-7045

15 1 Torch Control Cable Adapter for Unshielded Leads (includes item # 16) 7-3447

16 1 Through - Hole Protector 9-8103

1 Pinion Assembly (Not shown) 7-2827

   NN1PTJUJPOJOH5VCF/PUTIPXO  

NOTE

* Does not include Control Cable Adapter or Through - Hole

Protector.

Refer to Section 6.05 for Replacement Shielded Leads As

semblies.
