APPENDIX A-18 Manual 0-2962
APPENDIX 7B: PAKMASTER 50XL PLUS SYSTEM DATA
(MACHINE TORCH)
Cut Quality on Various Materials and Thicknesses
The following table defines the cut quality on various
materials and thicknesses:
Cut Quality on Various Materials
Material Type of Type of Cut
ThicknessMaterialGas Characteristics
Gage
to
1/2 inch
( 12.7 mm )
Good - Excellent
Good
Good
Air
Air
Carbon Steel
Stainless
Aluminum
Air
Description of Cut Characteristics:
Excellent - Minimum bevel (0 - 4°), minimum kerf (2 x
tip orifice diameter), little or no dross, smooth
cut surface.
Good - Slight bevel (0 - 10°), slightly wider kerf (2 - 1/2 x
tip orifice diameter), some dross (easily removed),
medium - smooth cut surface, slight top edge
rounding.
Output
Range
Dept
idth
Tip A 40 Amps Max. ShallowNarrow
Tip B 40-100 Amps Deep Narrow
Tip C40-100 Amps Moderate Moderate
Tip D40-100 Amps Shallo
ApplicationElectrode
Starter
Cartridge
Tip
Shield
Cup Body
Shield Cap
or Deflector
Shield Cup
9-82159-82139-8208 (40A)NoneNone 9-8218
9-82159-82139-8208 (40A)9-8237
9-8245 or
9-8243
None
Gouging9-8215 9-8213
Tip A: 9-8225 (40 A Max)
Tip B: 9-8226 (40-100 A)
Tip C: 9-8227 (40-100 A)
Tip D: 9-8228 (40-100 A)
9-8237 9-8241 None
SL100 Machine Torch Consumables for 40-Amp Power Supply
Standoff Cutting
Cutting Range
Material Mild Steel
Production Cut:
Up to 1/4 inch - 6.3 mm
Speed 45 ipm / 1.14 mpm
Genuine Cut:
Up to 1/2 inch - 12.7 mm
Speed 12-14 ipm / 0.3 - 0.36 mpm
Seve rance Cut:
Up to 3/4 inch - 19 mm
Speed 5-7 ipm 0.13 - 0.18 mpm
Pierce Rating
Material Mild Steel
Thickness:
Hand Cutting1/2 inch - 12.7 mm
Machine Cutting1/4 inch - 6.4 mm
Transfer Distance
3/8 inch - 9.5 mm
Gouging
Width3/16 inch - 4.8 mm
Depth1/8 inch - 3.2 mm
Number PassesSingle
Speed 20 ipm / 0.5 mpm
Bevel Cut Capability
Degrees0° to 45°
Material Thickness3/8 inch - 9.5 mm
Gas Requirement
Type GasAir
Operating Pressure 60 psi / 4.1 bar
Max Input Pressure 125 psi / 8.6 bar
Total Flow Rate:
Cutting 350 scfh / 165 lpm
Gouging230 scfh / 108.5 lpm
Torch Specifications For
PakMaster 50XL Plus Power Supply
