APPENDIX A-4 Manual 0-2962
APPENDIX 3A: CUTMASTER 50 & CUTMASTER 51 SYSTEM DATA
(HAND TORCH)
Cut Quality on Various Materials and Thicknesses
The following table defines the cut quality on various
materials and thicknesses:
Cut Quality on Various Materials
Material Type of Type of Cut
ThicknessMaterialGas Characteristics
Gage
to
1/2 inch
( 12.7 mm )
Good - Excellent
Good
Good
Air
Air
Carbon Steel
Stainless
Aluminum
Air
Description of Cut Characteristics:
Excellent - Minimum bevel (0 - 4°), minimum kerf (2 x tip
orifice diameter), little or no dross, smooth cut
surface.
Good - Slight bevel (0 - 10°), slightly wider kerf (2-1/2 x tip
orifice diameter), some dross (easily removed), me-
dium - smooth cut surface, slight top edge rounding.
Cutting Range
Material Mild Steel
Genuine Cut:
Up to 1/2 inch - 12.7 mm
Speed12-14 ipm / 0.3 - 0.36 mpm
Pierce Rating
Material Mild Steel
Thickness:
Hand Cutting1/2 inch - 12.7 mm
Machine Cutting1/4 inch - 6.4 mm
Transfer Distance
3/8 inch - 9.5 mm
Gouging
Width3/16 inch - 4.8 mm
Depth1/8 inch - 3.2 mm
Number PassesSingle
Speed20 ipm / 0.5 mpm
Bevel Cut Capability
Degrees0° to 45°
Material Thickness3/8 inch - 9.5 mm
Gas Requirement
Type GasAir
Operating Pressure 75 psi / 5.2 bar
Max Input Pressure 125 psi / 8.6 bar
Total Flow Rate:
Cutting350 scfh / 165 lpm
Gouging230 scfh / 109 lpm
Torch Specifications For
CutMaster 50 & CutMaster 51 Power Supplies
Output
Range
Dept
hW
idth
Tip A 40 Amps Max. ShallowNarrow
Tip B 40-100 Amps Deep Narrow
Tip C40-100 Amps Moderate Moderate
Tip D40-100 Amps Shallo
wW
ide
Gouging Profiles
ApplicationElectrode
Starter
Cartridge
Tip
Shield
Cup Body
Shield Cap
or Deflector
Shield Cup
Drag Cutting9-82159-8213 9-8207 (40A)NoneNone9-8218
9-8215 9-8213 9-8208 (40A)NoneNone9-8218
9-8215 9-8213 9-8208 (40A)9-8237
9-8244 or
9-8243
None
Gouging9-82159-8213
Tip A: 9-8225 (40A Max)
Tip B: 9-8226 (40-100A)
Tip C: 9-8227 (40-100A)
Tip D: 9-8228 (40-100A)
9-8237 9-8241 None
SL60 - SL100 Hand Torch Consumables for 40-Amp Power Supply
Standoff Cutting
