Thermaltake Level 20 - Default Chapter; Table of Contents; Specification

Radiator Support
4 mm Tempered Glass x 3 (Left)
2.5” or 3.5”x6 (HDD Cage), 2.5” or 3.5” x 2 (HDD Bracket)
2.5”x 3 or 3.5”x2 (HDD Bracket)
8+2
Chassis Dimension
(D*W*H)
Case Type
Side Panel
Drive Bays
- Accessible
- Hidden
Expansion Slots
Fan Support
Clearance
CPU cooler height limitation: 200 mm
VGA length limitation: 260 mm (With Thick Radiator + Fan)
310 mm (Without Radiator)
PSU length limitation: 220 mm
Exterior: Space Gray(Aluminum) ; Interior : Black
Color
SPCC + Aluminum
Material
Storage/LCS Chamber
4 x 120 mm, 3 x 140 mm
M/B Chamber
Front:
3 x 120 mm, 2 x 140 mm
Rear:
1 x 120 mm, 1 x 140 mm
Storage/LCS Chamber
1 x 480 mm, 1 x 420 mm
M/B Chamber
Front:
1 x 360 mm, 1 x 280 mm
Rear:
1 x 120 mm, 1 x 140 mm
Motherboards
6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX),
12” x 9.6” (ATX), 12” x 13” (E-ATX)
732 x 280 x 688 mm (28.8 x 11 x 27.1 inch)
Full Tower
Cooling System
(Main Area)
Rear (exhaust) :
140 x 140 x 25 mm Riing Plus RGB fan (500-1400 rpm, 27.2dBA)
Front (intake) :
140 x 140 x 25 mm Riing Plus RGB fan (500-1400 rpm, 27.2dBA) x2
USB 3.0 x 4, Type-C x 1, HD Audio x 1
I/O Port
Chapter 1. Product Introduction
Specification
Accessory
Warning and Notice
1.0
1.1
1.2
02
03
05
Contents
Chapter 2. Installation Guide
2.0
2.1
2.2
2.3
2.4
2.5
2.6-1
2.6-2
2.7
2.8
2.9
Side Panels Disassembly
Power Supply Unit (PSU) Installation
Motherboard Installation
3.5" & 2.5" HDD Installation
PCI Card Installation
Pump Installation
Air Cooling Installation
Liquid Cooling Installation
Radiator Installation Guide
Tt RGB Plus Installation
Tt RGB Plus Software control interface
07
09
11
12
13
15
16
16
17
19
21
Chapter3 Leads Installation Guide
Case LED connection
USB 3.0 connection
USB 3.1 connection
Audio connection
Thermaltake Power Supply Series (Optional)
Tt RGB Plus Ecosystem
3.0
3.1
3.2
3.3
3.4
3.5
23
23
23
24
25
27
